Escorts Silent Diesel Generators
Our range of products include 30 kva cpcb iv+ escorts silent diesel generator, 35 kva cpcb iv+ escorts silent diesel generator, 45 kva cpcb iv+ escorts silent diesel generator, 15 kva cpcb iv+ escorts silent diesel generator, 20 kva escorts powerlux silent diesel generator and 10 kva cpcb iv+ escorts silent diesel generator.
30 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 610000 / Piece Get Latest Price
Product Brochure
| Phase | 3 Phase |
| Power Rating | 30 kVA |
| Brand | Escorts |
| Cooling System | Liquid Cooling |
| Application | Industrial |
| Fuel Type | Diesel |
| Engine Model | G30-II |
| Dimension | 2400 x 1030 x 1410 mm (L x B x H) |
| Fuel Tank Capacity | 130 Liter |
| Rated Current | 130 Amp at 230 V, 42 Amp at 415 V |
| No Of Cylinders | 3 |
| Dg Set Model | ELG 30 |
| Weight | 870 Kg |
| Voltage | 415 V |
| Brake Horsepower | 46 BHP |
| Aspiration | TCIC |
| Aluminium Cable | 2C-95/3.5C-35 Sq. mm. |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
35 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 631000 / Piece Get Latest Price
Product Brochure
| Power | 35 kVA |
| Phase | Three Phase |
| Genset Type | Silent |
| Cooling System | Liquid Cooling |
| Fuel type | Diesel |
| Brand | Escorts |
| Application | Industrial |
| Noise Level | Silent or Soundproof |
| Engine Model | G40-II |
| Dimension | 2700 x 1030 x 1450 mm (L x B x H) |
| Capacity | 130 Liter |
| Rated Current | 152 Amp at 230 V, 49 Amp at 415 V |
| No Of Cylinders | 4 |
| Dg Set Model | ELG 35 |
| Weight | 945 Kg |
| Voltage | 415 V |
| Brake Horsepower | 58 BHP |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
45 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 722000 / Piece Get Latest Price
Product Brochure
| Phase | Three Phase |
| Genset Type | Silent |
| Cooling System | Liquid Cooling |
| Power Rating | 45 kVA |
| Brand | Escorts |
| Material | MS |
| Usage/Application | Industrial |
| Noise Level | Silent or Soundproof |
| Number Of Cylinder | 4 |
| Voltage | 415 V |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
15 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 370000 / Piece Get Latest Price
Product Brochure
| Phase | 3 Phase |
| Power Rating | 15 kVA |
| Brand | Escorts |
| Cooling System | Liquid Cooling |
| Fuel Type | Diesel |
| Engine Model | G15-II |
| Dimension | 2100 x 930 x 1400 mm (L x B x H) |
| Fuel Tank Capacity | 130 L |
| Rated Current | 66 Amp at 230 V, 21 Amp at 415 V |
| No Of Cylinders | 2 |
| Weight | 700 kg |
| 700 Kg | 415 V |
| DG Model | ELG 15 |
| Brake Horsepower | 23 BHP |
| Aspiration | Natural |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
20 KVA Escorts Powerlux Silent Diesel Generator
Request Callback
₹ 423100 / Piece Get Latest Price
Product Brochure
| Rated Power | 20 kVA |
| Power | 20 kVA |
| Genset Type | Silent |
| Phase | 3 Phase |
| Cooling System | Liquid Cooling |
| Genset Brand | Powerlux |
| Engine Make | ESCORTS |
| Noise Level | Silent or Soundproof |
| Frequency | 50 Hz |
| Fuel Tank Capacity | 130 Liter |
| Rated Current | 32 Amp at 230 V,10 Amp at 415 V |
| No Of Cylinders | 2 |
| Voltage | 415 V |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
10 KVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 341000 / Piece Get Latest Price
Product Brochure
| Power Rating | 10 kVA |
| Power | 10 kVA |
| Phase | 3 Phase |
| Brand | Escorts |
| Cooling System | Liquid Cooling |
| Material | MS |
| Application | Industrial |
| Noise Level | Silent or Soundproof |
| Engine Model | G12-II |
| Dimension | 1530 x 930 x 1160 mm (L x B x H) |
| Fuel Tank Capacity | 80 Liter |
| No Of Cylinders | 2 |
| Weight | 655 kg |
| Voltage | 415 V |
| DG Model | ELG 10 |
| Rated Current | 43 Amps at 230 V, 14 Amps at 415 V |
| Brake Horsepower | 18 BHP |
| Aluminium Cable | 2C-25/3.5C-16 Sq. mm. |
| Aspiration | Natural |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
20 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 396000 / Piece Get Latest Price
Product Brochure
| Rated Power | 20 kVA |
| Power | 20 kVA |
| Phase | Three Phase |
| Genset Type | Silent |
| Cooling System | Liquid Cooling |
| Brand | Escorts |
| Material | MS |
| Application | Industrial |
| Noise Level | Silent or Soundproof |
| Engine Model | G20-II |
| Dimension | 2300 x 930 x 1400 mm (L x B x H) |
| Fuel Tank Capacity | 130 Liter |
| No Of Cylinders | 3 |
| Dg Set Model | ELG 20 |
| Weight | 812 Kg |
| Voltage | 415 V |
| Brake Horsepower | 27.6 BHP |
| Rated Current | 87 Amps at 230 V, 28 Amps at 415 V |
| Aluminium Cable | 2C-50/3.5C-16 Sq. mm. |
| Aspiration | Natural |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
25 kVA CPCB IV+ Escorts Silent Diesel Generator
Request Callback
₹ 580000 / Piece Get Latest Price
Product Brochure
| Power Rating | 25 kVA |
| Power | 25 kVA |
| Phase | 3 Phase |
| Brand | Escorts |
| Cooling System | Liquid Cooling |
| Power Rarting | 25 KVA/20 KW |
| Application | Industrial |
| Noise Level | Silent or Soundproof |
| Engine Model | G25-II |
| Dimension | 2400 x 1030 x 1410 mm (L x B x H) |
| Fuel Tank Capacity | 130 Liter |
| Rated Current | 108 Amp at 230 V, 35 Amp at 415 V |
| No Of Cylinders | 3 |
| Dg Set Model | ELG 25 |
| Weight | 832 kg |
| Voltage | 415 V |
| Brake Horsepower | 37 BHP |
| Aspiration | TCIC |
| Escort Slient Diesel Generator | Value |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
40 kVA Escorts Silent Diesel Generator
Request Callback
₹ 760000 / Piece Get Latest Price
Product Brochure
| Rated Power | 40 kVA |
| Phase | Three Phase |
| Genset Type | Silent |
| Cooling System | Liquid Cooling |
| Fuel type | Diesel |
| Power Rating | 40 kVA |
| Brand | Escorts |
| Application | Industrial |
| Noise Level | Silent or Soundproof |
| Engine Model | G40-II |
| Dimension | 2700 x 1030 x 1450 mm (L x B x H) |
| Fuel Tank Capacity | 130 Liter |
| Rated Current | 174 Amp at 230 V, 56 Amp at 415 V |
| No Of Cylinders | 4 |
| Dg Set Model | ELG 40 |
| Weight | 1000 kg |
| Voltage | 415 V |
| Brake Horsepower | 58 BHP |
| Aspiration | TCIC |
| Aluminium Cable | 2C-120/3.5C-50 Sq. mm. |
Other Essentials:
How to Calculate Load:
Note:
- Engines are tested as per BS5514, IS: 10002 and IS01000B respectively.
- Superior quality alternators are used confirming to lS13364, IS4722 & BS5000 standards.
- Technologically advanced control panels with Deep-sea / Procom controller. Heavy, robust and sound efficient DG sets confirming to CPCB-II norms & Rule 95 of environment protection of GSR no of 771(E) & GSR 232(E).
How to Calculate Load:
- Put on only those equipment's which you want to run on the Powerlux Silent Generator.
- Go near the distribution box where you'll find four colored cables; Red, Yellow, Blue & Black.
- Put the clamp meter around the Red, Yellow & Blue cable one by one and note down the ampere rating.
- Now add the numbers in case of single phase requirement or pick the highest in case of three phase requirement.
- Select your kVA from the above given ampere chart and see under which rating your requirement falls.
Note:
- After putting the clamp meter around the cable; turn off and on the heavy machines/equipment's for better calculation. Also always select a rating 20% higher to your load for long term usage.
- AII of the above silent genset range is made to perform at 1500 rpm.
- Rated current output is at 100% load.(0.8 Power Factor).
- Weight mentioned is approximate.
- Product innovation is a continuous process; hence data given is subject to change without any prior notice.
- Detailed technical specification sheet separately available for each rating in soft copy.
X
Product Videos
Contact Us
Harjappun Gulati (Owner)
Powerlux Industries Private Limited
Capital Filling Station, Raisen Road, Patel Nagar
Bhopal - 462024, Madhya Pradesh, India
Send Email
